All product information at a glance
Product Description
Premium air conditioning heat pump Blaupunkt / Midea AC3.5S1R32 R32 Wifi Split 3.5KWA+++/A+++
Blaupunkt 3.5kW AC3.5S1R32 air conditioner
Energy-efficient and reliable heating
Extremely high heating efficiency and the ability to efficiently heat rooms at outside temperatures as low as -25°C. WIFI modules as standard
Environmentally friendly refrigerant R32
Multifunctional remote control
Wide temperature range
Minimalism at its finest!
For your health: i-Clean technology eliminates dust, mold, and grease that can cause unpleasant odors. An internal fan dries the evaporator, preventing mold growth and keeping the interior clean.
Extremely quiet operation!
It's so quiet that it won't even disturb a newborn's sleep. The "Do Not Disturb" feature allows you to turn off the indicator ring and display to ensure a peaceful and comfortable sleep.
Comfort!
When a conventional air conditioner is in operation, the room temperature fluctuations lead to instability. Our air conditioners are distinguished by a unique technology. The "Follow Me" function allows the unit to respond to the user's needs. The air conditioner regulates the room temperature based on the temperature around the control unit. The air outlet moves automatically both horizontally and vertically, ensuring that pleasant, cool air reaches every corner of the room.
With its refrigerant leak detection function, it can better prevent compressor damage due to refrigerant leakage or overload. The system automatically stops operation to ensure safety. The baseboard heater can quickly melt snow and ice on the outdoor unit, ensuring heating performance remains stable.
Energy saving!
Thanks to intelligent on/off technology, Blaupunkt products can automatically switch to energy-saving mode in standby mode, reducing power consumption from the usual 4-5W to 0.5-1W, resulting in savings of up to 80%! By utilizing an optimized fan and thanks to the new design, the ducts deliver the same airflow with 30% less power. This makes the air conditioner an unbeatable choice when it comes to energy savings.
Intelligent control!
With the control, you can remotely turn the air conditioner, alarm, and central control on and off, thus customizing the unit to your needs. If the house is empty for long periods in winter, the air conditioner ensures that the room temperature remains constant at 8 degrees Celsius, thus preventing household items from freezing. The speed of the outdoor fan can be varied depending on the condenser temperature. This allows the air conditioner to operate smoothly even at low temperatures (down to -15 degrees Celsius).
Intelligent control and Wi-Fi connection!
You can control your air conditioner from anywhere in your home! Thanks to a special app, you have this option, ensuring comfort and peace of mind. Furthermore, thanks to the easy operation, even elderly people or children can change the air conditioner settings via the app.
Technical data of the AC3.5S1R32 air conditioner:
Blaupunkt AC3.5S1R32
Model indoor unit BLP03.5P1AC1NR32
Outdoor unit BLP03.5P1AC1SPR32
Power supply Ph-V-Hz 220-240V, 1Ph, 50Hz
Rated cooling capacity Btu/h 12000 (4700~14700)
Energy consumption W 1005 (130~1650)
Working current A 4.37 (0.6~7.2)
Energy Efficiency Ratio (EER) W/W 3.5
Nominal heat output Btu/h 13000 (3640~14950)
Energy consumption W 977 (160~1560)
Working current A 4.24 (0.7~6.78)
Coefficient of performance (COP) W/W 3.9
Seasonal cooling performance coefficient Cooling load kW 3.5
Seasonal Energy Efficiency (SEER) W/W 8.5
Heating (cold season) heating load kW 3.3
Compressor type rotary compressor
Refrigerant type R32 Global Warming Potential (GWP) 675
Weight net/gross kg 8.7/11.5
Outdoor unit dimensions (W/D/H) mm 765x303x555
Net/Gross weight kg 26.4/28.7
Liquid/Gas mm (inch) 6.35 mm (1/4 in)/9.52 mm (3/8 in)
Maximum installation length m 25
Maximum level differences m 10
Subject to technical changes and errors! Subject to prior sale! Illustration similar!
Technical Data
Installation instructions | Download PDF |
---|
Installation
Notes
Manufacturer Information
TALISMAN BRANDS (Luxembourg) S.A.R.L. 6B, route de Trèves 2633 Senningerberg Luxembourg Email: info(at)blaupunkt.eu
