Hisense Hi-Therma Split Heat Pump 6kW (8.9kW) Indoor Unit + Outdoor Unit R32 A+++

Hisense Hi-Therma split heat pump 6kW (8.9KW) AHW-060HCDS1 + AHM060HCDSAA

High energy efficiency:

Hi-Therma is an efficient solution for heating and domestic hot water supply. The system achieves energy efficiency class A+++ at low flow temperatures (35 °C) and A++ at medium flow temperatures (55 °C). This saves you money on energy bills and reduces electricity consumption as well as the environmental impact.

Highly efficient DC inverter twin rotary compressor:

A highly efficient DC inverter twin rotary compressor is the heart of the system. Its unique dual-pressure chamber design and symmetrical arrangement effectively reduce vibrations and noise, improve compressor performance, and ensure excellent results, especially during low-frequency operation. Featuring a low lubricating oil injection quantity and stable oil return, the twin rotary compressor is equipped with a gas-liquid separator, further enhancing system reliability.

Wide range of applications:

The Hi-Therma heat pump system offers a wide range of applications and ensures stable operation even at extremely cold outdoor temperatures down to -25°C. At this temperature, it can produce hot water for heating up to 60°C. The operating range for domestic hot water preparation is extended to 40°C. Additionally, the water in the domestic hot water storage tank can reach a maximum temperature of 75°C with an electric auxiliary heater, enabling regular and effective disinfection.

Smart Grid Interlock and PV-compatible: The Hi-Therma system can be operated cost-effectively and contribute to achieving carbon reduction targets by being integrated into a smart grid. Additionally, the system can utilize energy from other renewable sources through integration with photovoltaic (PV) systems. Connecting to a smart grid or a PV system allows the system's potential to be fully realized.

Two separate temperature circuits:

Two temperature zones can easily be achieved through separately controlled heating circuits. The mixing valve kit makes it possible to achieve different water temperatures for the underfloor heating and the radiators.

Noise reduction:

Sound-dampened operation: The air/water heat pump system can ensure optimal user comfort thanks to its quiet operating mode. This mode can be easily activated via the controller or set by adjusting the input and output settings. A noise reduction of up to 8 dB(A) is possible.
Night Mode Operation: The night mode allows the operating time to be freely adjusted according to the user's needs. The sound pressure level can be reduced to as low as 35 dB(A)*. These settings can be conveniently adjusted via the control unit or external inputs/outputs.

Screed drying function:

The Hi-Therma air/water heat pump naturally features a special automatic program for screed drying, essential when building a house with underfloor heating. The screed drying process takes seven days. During the first three days, the system operates with a water outlet temperature of 25°C, and for the following four days with the maximum water outlet temperature preset by the installer to optimize the drying process.

Intelligent app control:

The Hisense Smart APP control offers a convenient way to control the heating system from anywhere, anytime, especially for those who travel frequently. How it works: After connecting the Hi-Mit adapter to the internet via a wireless or wired connection, users can control the Hi-Therma system anytime, anywhere with their smartphone and operate all functions via the app.

Split version:

The Hi-Therma Split series is an air-to-water heat pump system in which the indoor and outdoor units are installed separately. The indoor unit contains a plate heat exchanger, a circulation pump, and an expansion vessel. The split design allows for flexible installation and offers many advantages, including high energy efficiency and significant space savings. An additional buffer tank (for heating water) is still required.

• Power: 6kW
• Type: Split
• Outdoor unit: AHW-060HCDS
• Indoor unit: AHM-060HCDSAA
• Power supply: AC 1Φ, 220~240V/50Hz
• Power consumption: 50W
• Refrigerant type: R32
• Refrigerant quantity: 1.23 kg
• SCOP: 4.93 (water outlet temperature 35°C), 3.33 (water outlet temperature 55°C)
• Number of phases: 1
• Compressor: Rotating
• Dimensions of the outdoor unit: 750×900×340mm
• Dimensions of the indoor unit: 890×520×320mm
• Weight of the outdoor unit: 49.5 kg
• Weight of the indoor unit: 43.5 kg
• Water outlet temperatures up to 60 °C
• Energy efficiency class A+++
• Efficient operation at low outdoor temperatures down to -25 °C
• Direct connection to the building's existing water-based heating system
• Drinking water available as an option
• Two separate temperature circuits for radiators and underfloor heating
• Independent temperature control in up to 7 rooms
• Intelligent app control
• Maximizing efficiency through connection to the smart grid and photovoltaics
• Federal funding for efficient buildings

Important NOTE!

The installation and commissioning of the equipment must be carried out exclusively by qualified personnel. In the event of a complaint, proof of proper installation by qualified specialists (certificate of professional qualification and special qualifications) must be provided. If no such proof is provided, all warranties and guarantees will be void.

Technical specifications subject to change without notice. Errors and omissions excepted. Subject to prior sale. Image may differ from actual product.
