Product Description
Air Conditioner Midea BreezelessE Single Split Wall Unit SET 2.79 kW MSCB1BU-09HRFN8-ME-Set R32 A++/A+
Equipped with the latest intelligent learning algorithm, the Midea BreezelessE can proactively calculate various options for better air conditioning and energy efficiency. It offers a comprehensive, comfortable experience through Breezeless cooling, powerful heating, Air Magic+ sterilization, and over-the-air technology for updates.

Intelligent energy-saving technology
The latest intelligent algorithm can proactively detect changing environmental factors every 30 seconds and adjust the temperature for additional energy savings of up to 20%.

Breezeless cooling comfort
5013 miniature holes with an hourglass structure ensure gentle cooling of the air. 6.3°C within 10 minutes.¹

Fast heating as a heat pump
Instantly warms in cool weather down to -2°C. Heats the air to 10.4°C within 10 minutes.²
Excellent performance from Midea:
Fresh air quality with Midea filter technology
Technical data:
Manufacturer: Midea
Indoor unit model name: MSCB1BU-09HRFN8-ME
Outdoor unit model name: MOX103-09HFN8-ME
WiFi: Yes
Cooling capacity: 2.79 kW
Heating output: 2.93 kW
Cooling capacity (min. - max.): 1.02 kW - 3.52 kW
Heating output (min. - max.): 1.02 kW - 3.81 kW
BTU: 9000
Energy efficiency class cooling / heating: A++/A+
SEER: 7.6
SCOP: 4.1
Indoor unit noise level (min/max, in dB(A)): 20.5 , 20.5 | 37
Outdoor unit volume (max, in dB(A)): 55.5, 55
Cooling power consumption: 776 W (80~1300)
Heating power consumption: 696 W (100~1250)
Cooling/heating operating range in °C: -15 to +50°C / -20 to +24°C
Weight (indoor unit / outdoor unit): 9.1 | 22.7, 9.1
Pipe length AG – IG Max.: 25 m
Height difference IG – AG Max.: 10 m
Refrigerant: R32
Refrigerant pre-charge (m): 5 m
Refrigeration line diameter liquid / gas: 1/4" / 3/8" inch (6.35 / 9.52 mm)
Indoor unit dimensions in mm (WxHxD): 812x299x199
Outdoor unit dimensions in mm (WxHxD): 720x495x270
Power supply (V/Hz/Ph): 220-240 , 220-240 | 50 | 1
Current – 50 Hz Max. fuse amperage: 16 A
Recommended cable cross-section | Supply cable to outdoor unit: 3x2.5 mm²
Recommended cable cross-section | Indoor unit to outdoor unit: 5x1.5 mm²
Supply cable to outdoor unit: 3x2.5 mm²
Indoor unit to outdoor unit: 5x1.5 mm²
Number of rooms: 1 room
Device type: Cooling, Cooling | Heating | Ventilation | Dehumidification
Device type: Wall unit set
Total area: 1 m² - 30 m², 31 m² - 40 m²
Cooling capacity range: 2.5 kW – 3.4 kW
Heating power range: 2.5 kW – 3.4 kW
Technical changes and errors excepted! Subject to prior sale! Illustration similar!
