Sunex heat pump 18kW NEXUS M18 EVI R32 monoblock for domestic hot water and heating

Sunex heat pump 18kW NEXUS M18 EVI R32 monoblock for domestic hot water and heating

3.299,00 €
3.299,00 € 4.698,00 €
Taxes included.
Energieeffizienzklasse für Kühlen

Shipping method: Freight forwarding

Delivery time: Approx. 2-3 working days for standard items, forwarding delivery approx. 10-15 working days

Free shipping in Germany for orders over €50. Other EU countries additional shipping costs .

A++ A+++

Get personal consultation: 0157 / 35503770

Or send us a request via our contact form

View full details

All product information at a glance

Product Description

Sunex 18kW NEXUS M18 EVI R32 Monoblock Heat Pump for Domestic Hot Water and Heating A+++/A++

Circulation pump not integrated!

Sunex monoblock inverter heat pumps are eligible for subsidies and listed by BAFA.


The heat pumps are equipped with a continuously variable compressor and a brushless fan with variable speed control. This allows the heat pump to adapt to the energy demands of the heat consumers.

Adjust the settings. The heat pump's stable operation enables high performance with low compressor noise. The refrigeration system, equipped with EVI (Enhanced Vapor Injection) technology, ensures high efficiency even with conventional radiator systems.

  • One of the most cost-effective ways to heat buildings. The system also works at temperatures as low as -25°C.
  • High efficiency and long service life thanks to the use of components from world-renowned manufacturers
  • A comprehensive control system ensures optimal monitoring and security. Internet control is possible. A wired control panel is included as standard.
  • High ease of use. Intuitive and simple operation of the controls.
  • The device's compact design allows for quick installation.
  • Energy class A++ at 55°C flow temperature, A+++ at 35°C flow temperature

The ultimate feeling of comfort

NEXUS M EVI heat pumps enable optimal room temperature with minimal energy consumption. They allow the right air temperature to be achieved while simultaneously providing access to hot water to fully meet consumer needs.

Advantages of monoblock construction

The pump is designed entirely for outdoor installation. A key feature of the pump is that the entire cooling system is housed in a single unit, with only the pipes supplying heat to the building extending outside.

Working under extreme conditions

NEXUS heat pumps are innovative system solutions from SUNEX that keep your home warm even at extremely low temperatures down to -25 degrees Celsius. In operation, they offer exceptional efficiency, reliability, and cost-effectiveness.

Working under extreme conditions

NEXUS heat pumps are innovative system solutions from SUNEX that keep your home warm even at extremely low temperatures down to -25 degrees Celsius. In operation, they offer exceptional efficiency, reliability, and cost-effectiveness.

Technical data:

  • SCOP (W35) temperate climate: 4.46 kWh
  • SCOP (W55) temperate climate: 3.51 kWh
  • Energy efficiency class (W35): A+++
  • Energy efficiency class (W55): A++
  • Compressor: Panasonic (rotating, multi-stage vapor injection)
  • Expansion valve: electronic
  • Number of fans: 2
  • Circulation pump: no
  • Water-side pressure loss: 35 kPa
  • Control: Standard control module
  • Outside temperature: -25 to +45°C
  • Flow temperature: 55°C
  • Recommended heating water flow rate: 3.1 m³/h
  • Work equipment / GWP: R32 / 675
  • Amount of refrigerant R32: 2.7 kg
  • Defrosting method: Hot gas (reverse cycle)
  • Sound power level: 57dB
  • Dimensions: 1050x480x1330mm
  • Weight (net/gross): 170/180 kg
  • Power supply: 380-450V 3~ 50Hz
  • Max. current (heating/cooling/hot water): 6.37/6.28/7.15A

Important NOTE!

The installation and commissioning of the equipment must be carried out exclusively by qualified personnel. In the event of a complaint, proof of proper installation by qualified specialists (certificate of professional qualification and special qualifications) must be provided. If no such proof is provided, all warranties and guarantees will be void.

Technical specifications subject to change without notice. Errors and omissions excepted. Subject to prior sale. Image may differ from actual product.

Technical Data

Data sheet Download PDF
Installation instructions Download PDF
Investment book Download PDF

Installation

gid://shopify/GenericFile/36601011699924

Notes

Note: The air conditioner may only be installed by a company certified under Regulation (EU) No. 517/2014 of the European Parliament and of the Council of April 16, 2014, on fluorinated greenhouse gases. By purchasing a split air conditioner, you confirm that it has been professionally installed by certified specialists. Refrigerant leaks contribute to climate change. Refrigerants with lower global warming potential (GWP) contribute less to global warming in the event of a leak than those with higher global warming potential (GWP). A leak of 1 kg of this refrigerant would therefore have a greater impact on global warming than 1 kg of CO2 over a 100-year period, proportional to the refrigerant's GWP value. Do not perform any work on the refrigerant circuit or disassemble the unit – always consult qualified personnel.

Manufacturer Information

SUNEX SA Ziegelweg 7 02906 Niesky Poland service@sunex-deutschland.de https://sunex-deutschland.de/
